When it comes to conserving our built heritage the old saying ‘If something’s worth doing, it’s worth doing right’ certainly comes to mind. It encapsulates the need to take sufficient time to understand a problem fully before committing to the most effective solution.
And this was the key to our approach when we were appointed by Chichester Festival Theatre (CFT). CFT were facing ongoing problems with deteriorating and failing concrete with complex conservation challenges. CFT is a Grade II* listed building and one of the five most important modernist theatres in England. It opened in 1962 and features a distinctive hexagonal concrete shell. However, a £22m restoration and upgrade program carried out between 2012 and 2014 had resulted in failed concrete repairs. Worse – the theatre’s facade was covered in a protective netting that spoiled the overall look of this important building.
AtkinsRéalis were recommended to CFT by Historic England after we had successfully restored the Grade II* listed Congress Theatre in Eastbourne. We were appointed by CFT in 2016 to undertake a wide-reaching study of available repair techniques and approaches. There were two key challenges. First, we needed to ensure our solution would not fail. Second, it was essential that the new repair should match the original concrete in situ as closely as possible. The overall modernist aesthetic of the theatre had to be maintained.
The repair area was the largest of its type ever to be undertaken using conservation techniques in the UK. Our conservation philosophy focused on a thorough understanding of this historic building and, importantly, we recommended using ‘like for like’ materials. This would mean the concrete used for the repair matched both the look and composition of the original.
Extensive trials and experimentation lasting 10 months were undertaken in conjunction with Price & Myers (Structural Engineers) and Triton Building Conservation to simulate site working conditions. We researched the original specification and aggregate mix and even contacted the people who built the theatre in the 1960s. These painstaking trials proved invaluable as the repairs were managed on site without issue.
The successful repair has helped to reinstate the original intended appearance of the main entrance to the theatre. Much of the project’s success was due to the incredible partnership developed between client, consultants and specialist contractor. We also involved Historic England and the 20th Century Society from the start.
The trials we carried out had positive ramifications not just for CFT but also in terms of advancing concrete conservation techniques. Tests undertaken a year after installation showed that the newly cast concrete is well bonded and performing as intended. The project was used by Historic England as a case study in an international research project with the Getty Institute into furthering understanding on the conservation of concrete.
Such is the quality in match achieved between the newly applied and the original concrete, many visitors to the theatre are unaware that a repair has been undertaken; a huge endorsement and one that we very much hoped for when starting out on this demanding project.
Please note that you are now leaving the AtkinsRéalis website (legal name: AtkinsRéalis Group inc.) and entering a website maintained by a third party (the "External Website") and that you do so at your own risk.
AtkinsRéalis has no control over the External Website, any data or other content contained therein or any additional linked websites. The link to the External Website is provided for convenience purposes only. By clicking "Accept" you acknowledge and agree that AtkinsRéalis is not responsible, and does not accept or assume any responsibility or liability whatsoever for the data protection policy, the content, the data or the technical operation of the External Website and/or any linked websites and that AtkinsRéalis is not liable for the terms and conditions (or terms of use) of the External Website. Further, you acknowledge and agree that you assume all risks resulting from entering and/or using the External Website and/or any linked websites.
BY ENTERING THE EXTERNAL WEBSITE, YOU ALSO ACKNOWLEDGE AND AGREE THAT YOU COMPLETELY AND IRREVOCABLY WAIVE ANY AND ALL RIGHTS AND CLAIMS AGAINST ATKINSRÉALIS, AND RELEASE, DISCHARGE, INDEMNIFY AND HOLD HARMLESS ATKINSRÉALIS, ITS OFFICERS, EMPLOYEES, DIRECTORS AND AGENTS FROM ANY AND ALL LIABILITY INCLUDING BUT NOT LIMITED TO LIABILITY FOR LOSS, DAMAGES, EXPENSES AND COSTS ARISING OUT OF OR IN CONNECTION WITH ENTERING AND/OR USING THE EXTERNAL WEBSITE AND/OR ANY LINKED WEBSITES AND ANY DATA AND/OR CONTENT CONTAINED THEREIN.
Such waiver and release specifically includes, without limitation, any and all rights and claims pertaining to reliance on the data or content of the External Website, or claims pertaining to the processing of personal data, including but not limited to any rights under any applicable data protection statute. You also recognize by clicking “Accept” that the terms of this disclaimer are reasonable.
The information provided by Virtua Research cited herein is provided “as is” and “as available” without warranty of any kind. Use of any Virtua Research data is at a user’s own risk and Virtua Research disclaims any liability for use of the Virtua Research data. Although the information is obtained or compiled from reliable sources Virtua Research neither can nor does guarantee or make any representation or warranty, either express or implied, as to the accuracy, validity, sequence, timeliness, completeness or continued availability of any information or data, including third-party content, made available herein. In no event shall Virtua Research be liable for any decision made or action or inaction taken in reliance on any information or data, including third-party content. Virtua Research further explicitly disclaims, to the fullest extent permitted by applicable law, any warranty of any kind, whether express or implied, including warranties of merchantability, fitness for a particular purpose and non-infringement.
The consensus estimate provided by Virtua Research is based on estimates, forecasts and predictions made by third party financial analysts, as described above. It is not prepared based on information provided by AtkinsRéalis and can only be seen as a consensus view on AtkinsRéalis' possible future results from an outside perspective. AtkinsRéalis has not provided input on these forecasts, except by referring to past publicly disclosed information. AtkinsRéalis does not accept any responsibility for the quality or accuracy of any individual or average of forecasts or estimates. This web page contains forward-looking statements based on current assumptions and forecasts made by third parties. Various known and unknown risks, uncertainties and other factors could lead to material differences between AtkinsRéalis' actual future results, financial situation, development or performance, and the estimates given here.
In many ways this has been an exemplary project. Repairing the theatre after two previous failures was a challenging proposition but a great many lessons were learned which if published, could be of very wide benefit. It was particularly satisfying to see that using matching materials and a careful conservative approach could succeed. Much of this was down to the individuals involved, whose supervision and expertise ensured high standards of workmanship and a quality result were achieved.
Chris Wood
Former Head of Research at Historic England
